Welcome to Power Devices and Systems Group

The Power Devices and Systems Group of IMB-CNM was established in 1985, has developed his research continuously since then and currently consists of 22 people.

The Group has been considered and financed as a Consolidated Research Group by the Generalitat de Catalunya (2017-SGR-1384) in all calls for these grants since its creation (from 2000 to date).




Its activity focuses on the design, fabrication, characterization and integration of power semiconductor devices, optimized for developing reliable and energy efficient converters and electronic systems, operating even in harsh environments (high temperature, radioactive environments, etc.).



The devices developed by the group on different semiconductors (Si, SiC, GaN, diamond), are fabricated in the Clean Room of the IMB-CNM and cover various application fields (traction, protection, high frequency, space, high energy, etc.).

The research work of the Group also aims to transfer the developed technology to national and international industry sector. The Group has three main research lines:

    * Silicon Power Devices
    * Wide Bandgap Semiconductor Devices
    * Power Systems Integration and Reliability.


IMB-CNM through its Power Devices and Systems Group (PDS) is part of the following platfoms:



  • FUTURED - Plataforma Tecnológica Española de Redes Eléctricas as a research center:

  • XRE4S - R+D+I Network Energy for Society as research center:
